COUNTRY BUILT TO LAST

Haagis Country 150D



  150D
Max load (kg) 15000
Total length (mm) 6520
Total width with standard wheels (mm) 2450
Standard wheels 500/50-17
Length of loading area (mm) 4190
Loading area (m²) 3,2
Chassis (mm) 2(200x120)
4 WD (roller drive between wheels)  Option
2 WD (inner drum drive) Option
Hydraulic brakes Option
Pneumatic brakes Option
Overrun braks -
Drawbar steering cylinders (pcs) 2
Max allowed crane (kNm) 80
Trailer weight w.o crane and wheels (kg) 1905
Recommended with cranes 670/700/720/850
Haagis Country 150D
